Visionary AI-Assist

The Visionary AI-Assist is a reliable assistance system, for example for the operators of mobile machines. The solution is characterized by the combination of a 3D camera for distance determination and AI-based person detection and can be used for collision avoidance: If people or objects are in the defined hazardous area, the sensor triggers warning messages. The data processing for this takes place on the device. The Visionary AI-Assist can also be retrofitted, and is easy to install and quickly integrated. The individually adjustable warning fields ensure smooth operation and efficient workflows. Visionary AI-Assist is also suitable for stationary area monitoring and navigation support on automated machines.

The basic principle:

Stereoscopy is what humans use to perceive their surroundings in three dimensions. With our eyes, we take two images from slightly different perspectives. This allows the brain to efficiently assign a distance to all viewed objects. The head does not have to be moved for this. A passive stereo camera uses the same principle

A stereo camera consist of two separate cameras and thus two sensors and lenses. Both cameras are separated by a fixed distance referred to as “baseline”. The field of view of the two cameras overlap and capture the scene at a slightly different angle. Objects in the two images appear in different positions. The closer an object is, the more it is shifted in the two images. This shift is called disparity. Due to a calibration of the two cameras it is possible to calculate depth and distance information based on these disparity values


Target branches

• Construction & mining machines
• Ports & cranes
• Agriculture & forestry

Environmental perception for mobile automation

• Object detection and classification
• Relative localization
• Automated guidance
• Navigation support

Process automation for mobile machines

• Log handling
• Filling level monitoring
• Soil structure / clod and stone size
• Volume measurement
